Advance XI Paraglider
Advance XI Paraglider
Real lightweight construction
Available from 3.4 kg with fully lightweight design: The XI uses a mix of 27 and 32 gm Porcher Skytex cloth. To save more weight the number of cells and sliced diagonals has been reduced. The stress distribution system has been reworked to coordinate these requirements. The result is a perfectly balanced entity.
Performing in all conditions
The XI combines light weight with the outstanding performance of the Performance-Intermediate IOTA 2. The High-end B wing features high pitch and directional stability in mobile air. This and its significant stability at speed encourage relaxed, hours-long flying – with performance you can call upon at any time
Unique Allround talent
As an allround talent the XI takes you wherever you would like to go: on a long cross country following a hike to a remote takeoff, as your first vol-bivouac companion, on a trip round the world or an evening Hike & Fly – the antidote for a busy day. Your creativity has no bounds with a XI.
XI – Allround Tourer
As a light and compact Performance-Intermediate from 3.4 kg the XI satisfies the most diverse pilots’ needs; and does it in style. Whether near or far, difficult flying or exciting adventure. The new light high-end B goes with you for bivouac flying, Hike & XC-fly tours, traveling or discovering new routes in remote regions. XI – realise your story.
Technology & Features
Double 3D-Diamond Shaping
A diagonal perspective in the two-fold 3D shaping computations works to counteract seam-gathering (ruching) and the effects of the vertical forces across the profile. This achieves an even smoother canopy surface at the leading edge.
The latest technology is incorporated in the XI: for example the Advanced Air Scoop for friendly stall behaviour, short C-Wires for maximum profile retention and Miniribs for a smooth, efficient trailing edge.
The XI has Sliced Diagonals inside the wing to provide ideal tension distribution at minimum weight. Extensive work on this technology enabled many line support points to be saved, as well as ensuring the stable shape of the canopy itself, even under demanding aerodynamic and mechanical conditions.
Pitch Control System
The XI has a modern pitch control system for its trailing edge, which interconnects with the B-level. It can be flown actively and steered by the C/B-levels when accelerated.
To make line sorting easier the XI A and brake lines are identified by different colours (grey and red) at the risers. Big ear lines, stabilo lines and the much-handled brake lines have a section of coloured cover running up from the riser end.
Edelrid Magix Pro lines differ from other uncovered versions because they undergo a detailed Thermo Shield treatment and have an additional UV-Protec-Coating, which filters out the sun’s damaging UV light. These finishing processes prolong life, provide resistance to dust and water, and, at the same time, minimise the loss of strength caused by UV radiation.
Very stable length
Compared with Dyneema, Aramid lines, in general, change their lengths very little. Edelrid “Magix Pro” demonstrates minimal stretching and shrinking – within a maximum 0.2 % – and this line has excellent return-to-original properties. Experience shows that paragliders, fully lined with Edelrid “Magix Pro”, do not require retrimming for very long periods. Original flying characteristics are retained even after much intensive use.
The use of “Magix Pro” for the XI does not put performance alone at the forefront. Line thickness is similar to that of traditional covereds. This measurement results in considerably higher strength for the same diameter, because the whole cross section shares the load – not just the core. The broad gauge of “Magix Pro” lines delivers longer life compared to similar thickness covered lines.
Inner loop reinforcement
Every XI line has internal loop reinforcement. To achieve this a length of the same line is spliced inside a loop, increasing its line diameter, and thus the surface area of loop to loop contact. This reduces pressure where thin line meets thicker, and avoids the problem of the thin line cutting into the other.
Outer loop reinforcement
Base line loops also have external covers to minimise wear where they meet their quicklink.
If you have to change a line the ADVANCE Softlink can be opened and closed without problem. No tool is needed. There’s a guide in the manual with the picture underneath. If you are not sure how to do this, or have any question, always ask an ADVANCE Service Centre.
