MENTOR 6 Light – Less weight, zero limits

Three-liner | 59 cells | 5.43 aspect ratio | 4,2 kilo weight – size S (EN/LTF B)

At home in the B class and travelling the world – the MENTOR 6 Light in size S is a hefty 850 grams lighter than its big brother, but offers the same ingenious new developments like Zig-Zag 3D-Shaping, the innovative Mini-Rib Vector Tape, Double-B Splits and new risers. Since sometimes during Hike&Fly you might get choppy conditions, the MENTOR 6 Light also comes with a plus trim in comfort next to the high performance.

The MENTOR 6 Light mainly differentiates itself from the MENTOR 6 in terms of weight. We chose weight-optimised Skytex 27 cloth on the upper and lower surface. Nice to know: We offer the same guarantee for this cloth as we do for our regular sail cloths. Why? It is very important to us that you can enjoy your NOVA wing for a long time. Despite its lightweight design, we use the most robust materials possible and on the wing nose we have additionally used double-sided coated 30D cloth.

Csm Nova Mentor6 Light Me 7040 Eadb169Af2

No compromises in comfort. Apart from the gallery lines, all lines are sheathed and nearly sort themselves. Instead of “Spaghetti-straps” we use new aerodynamically slim risers, whose design was based on the Speedbrake Riser. These ensure optimal C-steering and even at the launch lie comfortably in the hand. This means the MENTOR 6 Light is easy to inflate and the weight-optimised canopy climbs even more easily than the normal version.

Csm Nova Mentor6 Light Me 7036 Bf80F42433

A typical Mentor. Which means that you can expect exactly what the name MENTOR traditionally promises from our new glider: best performance in the EN B class. An experienced pilot will soon realise that the MENTOR 6 Light gives useful feedback about what is happening with the wing in flight and at the same time leaves enough room for manoeuvre to actively fly the glider’s great potential. Our new ergonomic brake handles make this even more comfortable.

Simply honest. The MENTOR 6 Light’s performance is easily accessible and is therefore suitable for local soaring as well as being perfect for ambitious FAI triangles, hike & fly and vol biv. In strong thermals it convinces with its relaxed and comfortable flying characteristics and, for its class, a very high level of passive safety (flat aspect ratio: 5.43). Especially for pilots who like to climb mountains on foot, the combined low weight and small packing size makes the MENTOR 6 Light an all-rounder: light on the back and as enthusiastic about going XC as you are.

Video

Short and compact

Zig-Zag 3D-Shaping. As well as the double 3D-shaped seams, there is an additional diagonal 3D-shaped seam on every cell. This forms a striking zig-zag pattern. The advantage of Zig-Zag 3D-Shaping is that this seam doesn’t run in the direction of the spanwise force. This means the seam runs more cleanly and is more aerodynamically advantageous. This innovation reduces the creases in the leading edge.

Weight-optimised cloth. We not only test the sail cloth for durability (high porosity or reduced tear resistance through UV damage or wear) but also for mechanical robustness, for example stretching. For quality control purposes we regularly take samples during serial production.

Csm Nova Mentor6 Light Me 7208 Kopie 5Cf7C28721

Mini-Rib Vector Tape. Mini-ribs increase the number of cells in the rear wing area and thus provide an aerodynamically more favourable trailing edge. The MENTOR 6 Light has an additional vector tape in this area. This tape reduces the crease that is created when braking. This markedly increases climb performance and handling. Additionally, there is a brake gathering system on the trailing edge. These features mean the MENTOR 6 Light has a beautiful, smooth trailing edge, even when the brakes are applied.

Csm Nova Mentor6 Light Me 7193 Landscape A3Dee4234A

New risers. The risers on the MENTOR 6 Light are a further development of the Speedbrake Riser and this means the B-line area is also shortened when the C-line area is pulled during accelerated flight. The advantage is that the when using C-steering, there is no performance-limiting crease between the B-line and C-line areas, which is otherwise typical in three-liners. The new MENTOR 6 Light comes with the new riser as standard, so no retrofitting of the Speedbrake Riser is necessary. The new risers are practical and lie comfortably in the hand – during groundhandling and when getting ready to launch.

Learn more about the new risers at News & Stories.

Csm Nova Mentor6 Light Me 7267 E5087D6Df8

Ergonomic brake handles. We developed the new brake handles for the MENTOR 6, so of course they also feature on the MENTOR 6 Light. The new brake handles have an ergonomic design and are comfortable to handle.

Double-B splits. These double-B splits are similar to the double-A splits in two-liners and these allow for a better load distribution in the chord direction. This ensures more stability and fewer creases between the individual line areas.

Small XXXS size for flyweights

Csm Nova Mentor6Light Fliegengewichte 4C07370Db3

It is important to us to build smaller sized wings with a weight range starting at 50 kg. Instead of just scaling down a larger wing, we considered in great depth the technical peculiarities of small wings to ensure that the XXXS had a balanced and suitable brake configuration which matches the size of the canopy. Therefore, the MENTOR 6 Light XXXS is a wing with its own, fully-fledged specification allowing both women and men to enjoy its excellent performance, safety features and impressive agility. This is our contribution to equal opportunities in flying.

Technical data

	Dimension	XXXS	XXS	XS	S	M
Number of cells		59
Projected span	m	8,1	8,5	8,9	9,4	9,8
Projected area	m²	16,5	18,2	20,2	22,2	24,2
Projected aspect ratio		3,9
Flat span	m	10,3	10,8	11,4	11,9	12,4
Flat area	m²	19,5	21,5	23,8	26,2	28,5
Flat aspect ratio		5,43
Line diameter	mm	0,7 / 0,8 / 1,0 / 1,2 / 1,3
Line length	m	6,1	6,4	6,7	7,1	7,4
Total line length	m	223	235	248	260	271
Max. chord	m	2,34	2,46	2,59	2,71	2,83
Min. chord	m	0,42	0,44	0,47	0,49	0,51
Weight	kg	3,2	3,55	3,9	4,2	4,5
Recommended take off weight	kg	55-70	60-80	70-90	80-100	90-110
Certification (EN/LTF)		B	B	B	B	B

Colours

Blue

Lime

Red

Pilot target group

The MENTOR 6 light is a paraglider with impressive performance which has – in the hands of an experienced pilot – a very manageable handling and extreme flight behaviour. Flying the MENTOR 6 light does require a level of skill. Although certified as EN B, the MENTOR 6 light is not suitable for beginners and occasional pilots. But any pilot with the ambition to advance their sound flying knowledge to another level will find a perfect partner in the MENTOR 6 light. Particularly experienced cross-country pilots who like to fly at top speed for long flights will love the enhanced performance of this glider.

Would you like to know if this is the right wing for you or would you like to test fly one? In both cases the best person to contact is your local NOVA dealer.

TEST MENTOR 6 / MENTOR 6 Light IN “CROSS COUNTRY”

Cross Country published a detailed review of the MENTOR 6 and MENTOR 6 Light. You can download the full review here (PDF in English). Thanks to Cross Country for the permission.

Conclusion:

“Your brain is your most formidable flying instrument, and the Mentor 6 and Mentor 6 Light will allow you to use it at full capacity. Secure and reassuring – with loads of performance in the tank – this is a wing that could take you all the way from evening floater to XC legend. There are always moments when you want more speed, more glide, but a pilot flying at 100% will always fly their best flight. This wing will enable a huge number of pilots to get to that level – and to do it with a feeling of safety, comfort and control.”

Technology

Light as a feather and robust.Very light but still durable: Light weight NOVA wings weigh little but are still robust enough to withstand the hard conditions of the mountains. The profiles are made out of durable cloth, so that this highly-stressed component does not deform – like it can with ultra-light material. This means we are able to guarantee consistent flying characteristics.

Under pressure.NOVA Air Scoop is an optimised air intake, which increases the internal wing pressure. NOVA’s Air Scoop principle is similar to the ram-air inlet duct on a sports car: increased airflow produces higher pressure. Higher internal pressure in a paraglider means improved performance through increased structural stability and collapse resistance.

Flat profile nose. Anyone who tries to fold a piece of paper around a ball will notice that there are always creases. The nose profile of a paraglider is the same – the sail cloth has to adjust to both the profile and ballooning effect (cells are round, not straight). Double 3D Shaping uses additional seams to reduce creasing and therefore increases the performance of the wing.

Optimised cell widths. Smart Cells counteract the variable force distribution within the wing that are caused by the line attachments. In NOVA paragliders constructed using SmartCells, the cell widths have been adapted to the load – basically, intelligent cells. Wings with SmartCells fly more calmly, are more compact and glide better.

Comfort on the ground. All NOVA paragliders are made to be easy to use. For packing you can use a concertina bag, but it is not essential. Our extensive experience with rods has taught us that the packing method has little influence on the durability of the wing. Bent rods quickly spring back into their original shape.

Less is more. Our idea of a three-liner with a reduced amount of line length allows us to construct wings with very good performance and a high degree of passive safety. The way we have conceptualised the lines has made it possible to manufacture wings which are collapse resistant; but when they do collapse, the collapsed area is generally less extensive. This significantly improves the wing’s extreme flight behaviour.

MATERIALS

Leading edge: Dominico 30D, 41 g/m2
Top surface: Skytex 27 C2, 29 g/m2
Lower surface: Skytex 27 C1, 27 g/m2
Profile ribs: Porcher Skytex 32 Hard, 32 g/m2 (suspended)
Profile ribs: Porcher Skytex 27 Hard, 27 g/m2 (unsuspended)
Main lines: Liros PPSL 191 / U-8000 120
Gallery lines: Edelrid U-8000 / PPSLS 65
Brake lines:7850-240 / U-8000
Risers: Kevlar 12mm

Downloads

M

S

XS

XXS

Additional information

Weight	5 lbs
Color	Blue, Lime, Red
Size	M, S, XXS, XS
