Gin Condor 2 Paramotor Tandem Wing EXCELLENCE IN EFFICIENCY

The Condor 2 is our tandem and trike wing for powered flight. Its high efficiency and excellent roll and pitch stability reduces both fuel consumption and noise whilst providing an easy and fun piloting experience.

Compared to its predecessor, the Condor 2 has

  • better roll stability due to flatter arc
  • better pitch stability, especially no shooting on full trim
  • improved fuel efficiency due to aerodynamic performance
  • easier inflation, even in stronger winds

TECHNICAL SPECIFICATIONS

SIZE3741
Flat area (m2)37.0041.15
Flat span (m)14.0714.84
Flat aspect ratio5.355.35
Projected area (m2)31.2634.77
Projected span (m)11.0811.69
Projected aspect ratio3.93.9
Number of cells4949
Glider weight (kg)7.58.1
Certified weight range (paramotor) (kg)110-430130-472.5*
Certification (paramotor) (kg)DGACDGAC

* – if operating without a rescue system, the DGAC reduces the maximum permissible take-off weight to 450kg

Well co-ordinated rolling behaviour

Thanks to the flatter arc, the Condor 2 is stable and well co-ordinated in roll with most trikes on the market, even at full trim.

Condor 2Condor 2

Flawless take off and landing, every time

The Condor 2 inflates easily and progressively to naturally settle overhead. Even stronger wind launches present few problems due to the improved pitch stability. And because the profile produces a lot of lift at low airspeeds, you’ll get airborne quickly with the shortest of take-off runs.

Condor 2Condor 2

Built to last

The materials used in the Condor 2 have been carefully selected to withstand intensive use over a long lifetime. The main canopy fabric is Myungjin 40, which was developed for optimal strength — it proved impossible to break during our load testing, even at 635kg (5.25G)!

Condor 2Condor 2

Quiet efficiency

The Condor 2 has a moderate aspect ratio with a high performance profile. This results in efficient climbing even at high wing loadings, saving fuel and keeping the noise down. In addition, the glide performance remains good throughout the speed range.

Condor 2Condor 2

Excellent penetration and wide speed range

The profile of the Condor 2 enables excellent penetration in bumpy air and headwinds. Thanks to the long trimmers, the speed range is wide, yet it remains fully useable with a good margin of safety.

Condor 2Condor 2

Wide weight range

The Condor has a wide weight range and a high maximum weight. This makes it suitable for trike use, in addition to foot launched PPG. The 2 available sizes cover a weight range of 110-472.5kg.Condor 2

DESIGNER NOTES

Designer Gin Seok Song explains the development process of the Condor 2:

The development of the Condor 2 was a natural evolution, following improvements made to our Fuse tandem paraglider on which the wing is based. Almost all characterisics important for tandem paragliding are relevant to tandem paramotoring.

We were especially pleased with the increased pitch stability and overall aerodynamic efficiency. On take-off, the wing immediately stabilises above the pilot and the lift-off comes very early at low speed. In addition, the wing self-corrects into small directional gusts on take-off, which is a very useful characteristic if you have a heavy trike attached!

We believe pilots will appreciate the improved efficiency of the Condor 2, especially as pilots become more conscious of fuel consumption and noise pollution.

DETAILS

  • Optimized airfoil with 3rd generation Equalized Pressure Technology (EPT)
  • Thinner profile improves take-off and reduces material weight
  • 10cm trimmers for greater penetration
  • Long lifetime Myungjin MJ40 fabric
  • Güth & Wolf 25 mm polyester riser

MATERIALS

Canopy cloth

Upper surface: Myunjin MJ40 MF

Lower surface: Myunjin MJ40 MF

Risers

Güth & Wolf 25 mm polyester riser

Lines

Upper: Edelrid 7950 080 | Edelrid 7343 140 | 190

Middle: Edelrid 7343 140 | 230 | 280 | 420

Main: Edelrid 7343 420

COLOURS

ColoursColours

INCLUDED WITH YOUR GLIDER

DOCUMENTS

DGAC test report
